Effective Pixels | Panasonic CMOS 1/2.33 SENSOR |
Resolution | 1920×1080P |
Sensor Size | 1/2.33inch |
Pixel Size | 1.43um×1.43um |
Image Resolution | 6800 × 5100 (34MP) |
Frame rate | 60@FPS |
Image Format | JPEG |
WaveLength[nm] | 400nm~800nm |
Frame Fate | 1080 @60FPS; 720P 120@FPS |
Lens Fype | C / CS |
Frequency | 50Hz / 60Hz |
Storage | TF Card, Max 128G |
PC Support | Windows / Mac / Linux System PC Software with Measuring Function |
Image Measurement | Support HAYEAR Measurement |
Language | EN /FR /ES /Portugues /Deutsch /Italiano /CN/Pyccknn/ JP/DE |
Output Interface | HDMI/USB Standard usb2.0 interface (Type B) |
Image Scaling | 5-Fold zoom |
Transverse and vertical line | Support multi-color, 5 pcs of transverse lines/vertical lines, movable |
Encode | H.264 (High Profile) |
Video format | MP4 |
Input Voltage | DC 12V 1A |
Exposure | Auto/Manual, value adjustable |
Size | 75×60×39mm(LxWxH) |
