HY-1135 | |
Features | |
Model | Camera with HDMI USB2.0 two output |
Image format | JPEG |
Image resolution | 48Mega Pixel |
Video format | MP4(for TF card) |
Video recorder | 2K@30FPS, 1080P@60FPS |
HDMI Video resolution | 1920*1080 @ 60FPS |
USB Video resolution | 1920*1080@30FPS;1280*720@30FPS;640*480@30FPS; 320*240@30FPS |
White Balance | Auto/Manual |
Light | Auto/Manual |
Exposure | Auto/Manual, value adjustable |
Color | Color |
Mirror | Left/right,Up/Down |
Freeze | Support |
OSD | English/Chinese/French/Spanish/Japanese/German |
Line | different color,5 horizontal line , 5 vertical line, any positions |
Specification | |
Image sensor | 48 megapixel CMOS sensor 1/2.33’ |
Effective pixel | 48 megapixel |
Pixel size | 1.335μm × 1.335μm |
Frame rate | 60fps |
Definition | FULL HD |
Housing | metal |
Lens | C/CS |
Video format | MOV |
Digital Zoom | 5 times digital zoom |
Brightness control | Auto/manual |
Color | R/G/B adjustable |
Film and record | Support |
Cross cursor | Support scale cursor, size adjustable |
TF card interface | Max 128G |
HDMI interface | Standard HDMI output (Type A) |
USB interface | Standard usb2.0 interface (Type B) |
Input Voltage | DC 12V 1A |
