Full Set 1080P 60FPS 2K Industrial Microscope Camera HDMI USB Outputs with 180X C-mount Lens HY-1137B

343 Reviews

Model :


SKU: 1806262907



US $0.00

QTY:
- +
Shipping: US$0.00
Estimated Delivery on Please select Express Arrival time = dispatch + shipping time

Noting:


1:PC Support : Windows XP/7/8/10 system

2:For USB output, the white balance, exposure and color adjustment are automatic, they can't be adjusted. For HDMI output, the functions can only be adjusted while connecting with monitor, if you connect the camera with computer, the functions also can not be adjusted.


Features:


Model: Camera with HDMI USB2.0 two output

Image format: jpg

Image resolution: 4608*3456 (for TF card) 1920*1080 @ 60FPS(for TF card)

Video format: MOV(for TF card)

Video recorder: 1920*1080 @ 60FPS (for TF Card)

HDMI Video resolution: 1920*1080 @ 60FPS

USB Video resolution: 1920*1080 1280*720 640*480 320*240 @ 30FPS

White Balance: Auto/Manual

Light: Auto/Manual

Exposure: Auto/Manual, value adjustable

Color: Color

Morror: Left/right,Up/Down

Freeze: Support

OSD: English/Chinese/French/Spanish/Japanese/German

Line: different color,5 horizontal line , 5 vertical line,any positions


Specification:


Image sensor:16 megapixel Panasonic CMOS sensor 1/2.33 inch

Effective pixel:16 megapixel

Pixel size:1.335μm × 1.335μm

Frame rate:60fps

Definition:FULL HD

Housing:metal

Lens:C/CS

Video format: MP4, AVI

Digital Zoom:Support

Brightness control:Auto/manual

Color:R/G/B adjustable

Film and record:Support

Cross cursor:Support multi-color, size adjustable

Transverse and vertical line:

Support multi-color, 5 pcs of transverse lines/vertical lines, movable

Different color,5 horizontal line , 5 vertical line,any positions

TF card interface:Max 128G

HDMI interface:Standard HDMI output (Type A)

USB interface:Standard usb2.0 interface (Type B)

Input Voltage: DC 12V


C-MOUNT Lens:


Working distance: 95-125mm

Zoom c-mount Lens

0.5X C-mount adapter

Zoom ratios: 6.5:1

Objective Magnification Power by 0.7 - 4.5X(about 10 - 180X on the display)

Size: 180mm(L) * 50mm(DIA)

Weight: 500g


60 LED Light:


Light source: 60pcs LED

Input Voltage: AC90-240V

Output Voltage: DC12V

Output frequency: 4.5W

Working Distance: 40-160mm

Illumination: 30000LUX-35000LUX

color temperature: 6500K-7000K

brightness range control: 0% - 100%

light Color: cool white

Product Light:  >30000HRS

Valid optical length: 75mm

Valid optical path: 30mm

Power box size: 110 x 60 x 30mm

Material of power box: Plastic

Color: Black

Inside dia. Of Ring Light: 61.5mm

Outside dia. Of Ring Light: 94mm

Inside dia. Of ring holder: 26mm

Outside dia. Of ring holder: 45mm


8 Inch Monitor:


Panel Size: 8 inches

LCD Type: TFT LED

Physical Resolution: 800 × 600

Display Ratio: 4: 3

Display Color: 16.7M

Point Distance (mm): 0.264

Brightness (nits): 250cd / ㎡

Contrast Ratio: 300: 1

View (Up / Down / Left / Right): 160 ° / 160 °

Response Time: 6ms

Power Supply DC: 12V 1A

Field Frequency: 50Hz, 60Hz, 70Hz

Signal Interface: AVC × 1, BNC × 1, VGA × 1, HDMI × 1

Color Format: PAL / NTSC / SECAM

Menu Operation OSD: keypad / remote control

Menu Language (optional): Simplified Chinese, Traditional Chinese, English, Russian, French, Spainish, German, Italian

Installation: Base Support / Wall


Package Including:


1 x Microscope Camera

1 x 12V/1A Power supply

1 x USB line

1 x Software DISC

1 x 180X Zoom C-mount Lens

1 x Camera Stand

1 x 60-LED Ring Light with Power Adapter

1 x 8 inch Monitor
